Inverted Tissue Culture Microscope
Product Code : JA-M-956
The Inverted Tissue Culture Microscope (SKU JA-M-956) is listed for examining cells in culture vessels, with an oversize 180 x 150 mm plain stage and two 150 x 65 mm extension plates for large bottles and micro filter work. It has a 45-degree binocular head, interchangeable with monocular or trinocular heads, a quadruple revolving turret, achromatic 5x, 10x, LWD 20x and LWD 40x SL objectives, HWF 10x eyepieces and Koehler illumination from a 6 V 20 W halogen illuminator. JaincoLab manufactures it.
Specifications
As listed: 45-degree binocular head, interchangeable with monocular or trinocular; quadruple revolving turret nosepiece with click stops; 180 x 150 mm plain stage with two 150 x 65 mm extension plates; post-mounted 6 V 20 W halogen Koehler illumination; four achromatic objectives; HWF 10x eyepieces.
| Product | Inverted Tissue Culture Microscope |
| SKU | JA-M-956 |
| Head | Binocular, 45-degree inclined; interchangeable with monocular or trinocular |
| Nosepiece | Quadruple revolving turret, positive click stops |
| Stage | Oversize plain stage 180 x 150 mm; 2 extension plates 150 x 65 mm |
| Illumination | Koehler system, post-mounted 6 V 20 W halogen illuminator |
| Objectives | Achromatic 5x, 10x, LWD 20x, LWD 40x SL |
| Eyepieces | HWF 10x |
Applications of the inverted tissue culture microscope
Biotechnology and microbiology laboratories use it to check cell cultures in flasks, bottles and dishes and to examine micro filters, with the long working distance objectives reaching through the vessel wall.
- Checking cell cultures in flasks and dishes
- Micro filter examination
- Biotechnology teaching labs
- Cell biology practicals
- College research training
Scope of supply
One unit is one tissue culture microscope with binocular head, four objectives, HWF 10x eyepieces, stage with extension plates and halogen illuminator. Alternative heads, accessories, spares and quantities are confirmed on the quotation.
Packing, MOQ and lead time
Minimum order quantity, lead time and packing are confirmed on each quotation for the quantity ordered and the delivery destination. JaincoLab supplies single-school orders as well as bulk requirements for schools, colleges and education projects, and exports to buyers in Africa, the Middle East and South and South-East Asia.
JaincoLab supports tender contractors as well as institutions: we manufacture and export laboratory equipment for Ministry of Education projects, World Bank-funded tenders and United Nations programmes, executed successfully in many countries, and we specialise in turnkey laboratory set-ups. Contact us through the tenders page early in your bid preparation.
Frequently asked questions
Which objectives are fitted?
Achromatic 5x, 10x, LWD 20x and LWD 40x SL.
How large is the stage?
180 x 150 mm, with two 150 x 65 mm extension plates for large bottles and micro filters.
How does it compare with the Tissue Culture Microscope JA-M-876?
The listings give the same head, stage, lighting and objectives; this one also names HWF 10x eyepieces.
What should a quotation request include?
Send the SKU JA-M-956, the head type, the number of microscopes and the delivery destination.
