Wein Series Resistance Bridge
Product Code : JA-SI-8069
The Wein Series Resistance Bridge (SKU JA-SI-8069), the Wien series bridge of AC practicals, is built on one Bakelite board with its own 1 kHz sine wave source, which has two output sockets and an amplitude indicating lamp. A null detector with digital display is built in, and the listing notes that a small speaker can be used instead. Five unknown values are fitted on the panel and selected with a rotary switch, and the connections are made at 4 mm sockets on a spread-out layout.
Specifications
The listing gives these values:
| Product | Wein Series Resistance Bridge |
| SKU | JA-SI-8069 |
| AC source | 1 kHz sine wave, two output sockets, amplitude indicating lamp |
| Detector | Built-in null detector, digital display; small speaker optional |
| R2 | Two-decade dial, x10 and x100 |
| R1, R3, R4 | Decade dial, x100 |
| Unknowns | Five, on the panel, selected by rotary switch |
| Connections | 4 mm sockets, spread-out layout |
Experiments on the Wien series bridge
- Balancing the Wien series bridge against the five unknowns
- Study of AC bridge balance conditions at 1 kHz
- Comparison of null detection by digital display and by ear with the optional speaker
Scope of supply and ordering
The bridge is supplied with its source, detector and five unknowns; say if the speaker option is wanted.
