Rheostat 1325 ohm
Product Code : JA-EE-7511
The Rheostat 1325 ohm (SKU JA-EE-7511) is a high-value sliding rheostat of 1325 ohm with a maximum current of 0.5 A, used for fine current control and voltage division in electricity practicals. This 1325 ohm rheostat with 0.5 A rating is wound with heavily oxidised resistance wire on a vitreous enamel steel tube carried on die-cast end stands, with a nickel-plated sliding contact and 4 mm terminal posts. JaincoLab supplies it to schools and colleges.
Specifications
The Rheostat 1325 ohm has a resistance of 1325 ohm and a maximum current of 0.5 A, with heavily oxidised resistance wire wound on a vitreous enamel steel tube between die-cast end stands, a heavy-duty nickel-plated sliding contact and 4 mm terminal posts for a conventional 4 mm plug.
| Product | Rheostat 1325 ohm |
| SKU | JA-EE-7511 |
| Resistance | 1325 ohm |
| Maximum current | 0.5 A |
| Winding | Heavily oxidised resistance wire on a vitreous enamel steel tube |
| Supports | Die-cast end stands |
| Sliding contact | Heavy duty, nickel plated |
| Terminals | 4 mm terminal posts |
Applications of the 1325 ohm rheostat
With 1325 ohm and a 0.5 A limit, this rheostat is suited to potential divider arrangements and to circuits that need small, finely adjusted currents, such as meter and galvanometer work, bridge balancing and semiconductor characteristics.
- Potential divider for a finely variable supply voltage
- Small-current control in galvanometer and meter circuits
- Balancing adjustments in bridge experiments
- Diode and transistor characteristic curves at low current
- College and senior-school electricity practicals
Scope of supply and ordering
The listing covers one 1325 ohm, 0.5 A rheostat with sliding contact and 4 mm terminal posts. Leads, meters and supplies are separate items.
Frequently asked questions
What are the resistance and current rating?
1325 ohm, with a maximum current of 0.5 A.
How is it connected?
Through 4 mm terminal posts for a conventional 4 mm plug.
Is a higher value available?
Yes. A 1600 ohm rheostat is listed, along with lower values down to 2.5 ohm.
