Refractometer
Product Code : JA-MI-4929
The Refractometer (SKU JA-MI-4929) is a digital Brix refractometer for measuring the sugar content of solutions from 0 to 85% Brix, with a resolution of 0.1% Brix and an accuracy of 0.2% Brix. It also reads sample temperature from 0 to 80°C and applies automatic temperature compensation between 10 and 40°C. A reading takes about 1.5 seconds from a sample of 100 microlitres placed on the stainless steel ring and flint glass prism. It is supplied by JaincoLab for food, beverage, agriculture and quality control laboratories.
Specifications
The refractometer measures 0 to 85% Brix with 0.1% resolution and 0.2% accuracy, and temperature from 0 to 80°C with 0.1°C resolution and 0.3°C accuracy, using a yellow LED light source.
| Product | Refractometer |
| SKU | JA-MI-4929 |
| Brix range | 0 to 85% Brix |
| Brix resolution / accuracy | 0.1% Brix / ±0.2% Brix |
| Temperature range | 0 to 80°C (32 to 175°F) |
| Temperature resolution / accuracy | 0.1°C / ±0.3°C |
| Light source | Yellow LED |
| Measurement time | About 1.5 seconds |
| Minimum sample | 100 microlitres (prism fully covered) |
| Sample cell | Stainless steel ring and flint glass prism |
| Temperature compensation | Automatic, 10 to 40°C |
| Case | ABS |
| Battery | 1 x 9 V, about 5000 readings; auto shut-off after 3 minutes |
| Size and weight | 192 x 102 x 67 mm; 420 g |
Applications of the digital Brix refractometer
A digital Brix refractometer gives a fast, objective sugar reading from a few drops of sample, which is why it is used for mixing ratios, quality control and purity checks.
- Sugar content of fruit juices, syrups and beverages in food technology laboratories
- Mixing-ratio and concentration checks in quality control
- Ripeness testing of fruit in agriculture and horticulture practicals
- Refractometry exercises in college chemistry and food science courses
Scope of supply and ordering
The listing covers the digital refractometer with its 9 V battery. Calibration liquids and carrying cases are confirmed on the quotation.
Frequently asked questions
What range does it measure?
0 to 85% Brix, with 0.1% resolution and an accuracy of 0.2% Brix.
How much sample is needed?
About 100 microlitres, enough to cover the prism fully.
Does it compensate for temperature?
Yes. Automatic temperature compensation works between 10 and 40°C.
How is it powered?
By one 9 V battery, giving about 5000 readings, with auto shut-off after 3 minutes.
Related products
This instrument is listed in the JaincoLab measuring instruments range.
Request a quote
To order the Refractometer, send the quantity and delivery destination through the JaincoLab contact page or email [email protected], quoting SKU JA-MI-4929. Tender and project enquiries can be sent through the tenders page.
