Large Pull Out Test Apparatus for Geo Synthetics
Product Code : JA-GT-9866
The Large Pull Out Test Apparatus for Geo Synthetics (SKU JA-GT-9866) finds the pull-out interface properties of geogrids and other reinforcement in soil, including the interfacial friction between GI strips or geosynthetics and soil. The interfacial friction coefficient is a key design parameter for reinforced earth walls, reinforced slopes and other reinforcement applications. This large pull-out test apparatus is supplied by JaincoLab for geosynthetics and geotechnical engineering laboratories.
Specifications
The product data describes the purpose of the apparatus; box size, pull-out force capacity, normal load system and displacement measurement are not listed in the product data and are confirmed on the quotation.
| Product | Large Pull Out Test Apparatus for Geo Synthetics |
| SKU | JA-GT-9866 |
| Test | Pull-out of reinforcement from soil |
| Materials | Geogrids, geosynthetics and GI strips |
| Result | Interfacial friction coefficient and pull-out interface properties |
Experiments with the pull-out test apparatus
Students embed a geogrid or strip in compacted soil under a normal load and pull it out at a set rate, recording force and displacement to find the interface friction.
- Pull-out resistance of geogrids in soil
- Interfacial friction of GI strips and geosynthetics
- Design data for reinforced earth walls and slopes
- Comparing reinforcement products
- Geotechnical research and teaching
Scope of supply and ordering
This listing covers the large pull-out test apparatus as described. Loading, force measurement and displacement gauges are confirmed on the quotation.
Frequently asked questions
What does the test find?
The pull-out interface properties and friction coefficient of reinforcement in soil.
Which materials can be tested?
Geogrids, geosynthetics and GI strips.
Why is it important?
The interfacial friction coefficient is a key parameter for reinforced earth wall and slope design.
