Inverted Metallurgical Microscope
Product Code : JA-M-984
The Inverted Metallurgical Microscope (SKU JA-M-984) examines polished metal and other opaque specimens by reflected light, with the sample resting face down on a stage plate above the objectives. It has a 45-degree binocular head, a 170 x 166 mm coaxial mechanical stage, a 6 V 15 W halogen vertical illuminator and plan objectives up to semi-plan 100x. Engineering colleges and material science laboratories use this inverted metallurgical microscope for metallography practicals and sample inspection.
Specifications
The listing gives a binocular head inclined at 45 degrees, a coaxial mechanical stage of 170 x 166 mm with 28 x 24 mm movement and 10, 15 and 20 mm stage plates, a 6 V 15 W halogen bright field vertical illuminator, plan and semi-plan objectives, and three eyepieces including a reticle.
| Product | Inverted Metallurgical Microscope |
| SKU | JA-M-984 |
| Head | Binocular, inclined at 45 degrees |
| Stage | Coaxial mechanical stage 170 x 166 mm, movement 28 x 24 mm |
| Stage plates | Diameter 10 mm, 15 mm, 20 mm |
| Illumination | Bright field vertical illuminator, 6 V 15 W halogen; aperture diaphragm, filter slots, bulb centring |
| Objectives | Plan 10x, plan 40x, semi-plan 100x |
| Eyepieces | 10x, 12.5x and reticle eyepiece 10x |
Applications of the inverted metallurgical microscope
Because the specimen sits face down over the objective, only one face needs polishing and bulky pieces can be examined without levelling, so the inverted metallurgical microscope suits grain-structure studies and inspection of mounted metal samples in teaching laboratories.
- Grain structure of polished and etched metals
- Inspection of welds, alloys and coatings
- Metallography practicals in engineering colleges
- Material science and polytechnic laboratories
- Measurement of features with the reticle eyepiece
Scope of supply
One unit is one inverted metallurgical microscope with binocular head, coaxial stage, three stage plates, halogen vertical illuminator, three objectives and three eyepieces as listed. Filters, spare bulbs, accessories and quantities are confirmed on the quotation.
Packing, MOQ and lead time
Minimum order quantity, lead time and packing are confirmed on each quotation for the quantity ordered and the delivery destination. JaincoLab supplies single-school orders as well as bulk requirements for schools, colleges and education projects, and exports to buyers in Africa, the Middle East and South and South-East Asia.
JaincoLab manufactures and exports laboratory equipment for Ministry of Education programmes, World Bank-funded tenders and United Nations projects, and has executed these supplies successfully in many countries. Contractors bidding for such tenders can contact JaincoLab for specifications, quotations and turnkey tender supply.
Frequently asked questions
What kind of specimens can it examine?
Polished metal and other opaque samples, viewed by bright field reflected light from the vertical illuminator.
Which objectives are supplied?
Plan 10x, plan 40x and semi-plan 100x.
What stage plates are included?
Stage plates with 10 mm, 15 mm and 20 mm openings are listed.
What should a quotation request include?
Send the SKU JA-M-984, the quantity, any extra eyepieces or filters and the delivery destination.
