High-Voltage Power Supply
Product Code : JA-PLE-4265
The High-Voltage Power Supply (SKU JA-PLE-4265) delivers a variable DC output from 0 to 10000 V at up to 10 mA, together with a 6.3 V, 3 A AC output, and shows the output voltage on a display. It runs on 220-240 V AC mains. This 0-10 kV high voltage power supply is used in physics laboratories to operate electron-beam tubes and for high-voltage demonstrations in college and university practicals.
Specifications
The unit gives 0-10000 V DC at 10 mA and 6.3 V AC at 3 A from a 220-240 V AC (±10%) input, with a voltage display, in a 132 x 160 x 270 mm case weighing 2 kg.
| Product | High-Voltage Power Supply |
| SKU | JA-PLE-4265 |
| Input voltage | 220-240 V AC, ±10% |
| DC output | 0-10000 V, 10 mA |
| AC output | 6.3 V, 3 A |
| Display | Output voltage display |
| Dimensions | 132 x 160 x 270 mm |
| Weight | 2 kg |
Applications of the 0-10 kV high voltage power supply
The variable high-voltage DC output provides the accelerating voltage for electron-beam tubes, while the 6.3 V AC output can supply the tube heater, so one unit can run most teaching tubes used in modern physics practicals.
- Accelerating voltage for electron deflection, diffraction and Maltese cross tubes
- Heater supply from the 6.3 V, 3 A AC output
- Determining e/m and studying electron beams in magnetic and electric fields
- High-voltage demonstrations in electrostatics and gas discharge
- B.Sc and M.Sc physics and engineering physics laboratories
Scope of supply and ordering
The listing covers the high-voltage power supply with its DC and AC outputs and voltage display. Leads, tubes and tube holders are separate items.
Frequently asked questions
What outputs does the high-voltage power supply have?
A DC output variable from 0 to 10000 V at 10 mA and an AC output of 6.3 V at 3 A.
What mains input does it need?
220-240 V AC, ±10%.
What are its size and weight?
132 x 160 x 270 mm and 2 kg.
