Digital/Analogue Oscilloscope
Product Code : JA-MI-4922
The Digital/Analogue Oscilloscope (SKU JA-MI-4922) is a 40 MHz digital analogue oscilloscope with two channels that works both as an analogue instrument and as a digital storage scope. Sensitivity runs from 5 mV/div to 20 V/div, the analogue time base from 50 ns/div to 200 ms/div and the digital time base from 10 ns to 200 s/div, with single-shot sampling at 50 MS/s. It offers 17 automatic measurements, cursors, auto set, TV triggering and an RS232 link with SCPI programming. It is supplied by JaincoLab for electronics and physics laboratories.
Specifications
The oscilloscope has a 40 MHz bandwidth, two channels, 5 mV/div to 20 V/div sensitivity, analogue and digital time bases, 50 MS/s single-shot and 10 GS/s ETS sampling, and runs on a 96 to 264 V, 45 to 440 Hz supply.
| Product | Digital/Analogue Oscilloscope |
| SKU | JA-MI-4922 |
| Bandwidth | 40 MHz |
| Channels | 2 |
| Sensitivity | 5 mV/div to 20 V/div |
| Operating modes | CH1, CH2, XY, CHOP, ALT, ADD, -CH2 |
| Time base (analogue) | 50 ns/div to 200 ms/div |
| Time base (digital) | 10 ns to 200 s/div |
| Triggering | TV lines and frames; internal 0.5 to 1 div, external 100 to 200 mV |
| Sample rate | Single shot 50 MS/s; ETS 10 GS/s |
| Measurements | 17 automatic measurements and cursors |
| Other modes | Envelope, triggered roll, digital XY; auto set |
| Interface | RS232 serial link, SCPI programming |
| Power supply | 96 V to 264 V, 45 to 440 Hz |
| Supplied with | Mains lead, user manual, programming manual |
Applications of the 40 MHz digital analogue oscilloscope
A combined analogue and digital oscilloscope lets students watch live waveforms in analogue mode and capture single events or slow signals in digital mode.
- Waveform, frequency and phase measurements in electronics practicals
- Capturing single-shot and transient events in digital mode
- Lissajous figures and XY displays in physics laboratories
- Instrument interfacing exercises through RS232 and SCPI programming
Scope of supply and ordering
The listing covers the oscilloscope with mains lead, user manual and programming manual. Probes and PC software are confirmed on the quotation.
Frequently asked questions
What is the bandwidth?
40 MHz, on two channels.
Can it store single events?
Yes. In digital mode it samples single-shot signals at 50 MS/s.
Can it be connected to a computer?
It has an RS232 serial link and supports SCPI programming.
Related products
- Milli Ammeter
- Antenna, Satellite and Radar Trainers
- 2 Channel Digital Strain Meter
- Engineering Training Equipment
This instrument is listed in the JaincoLab measuring instruments range.
Request a quote
To order the Digital/Analogue Oscilloscope, send the quantity and delivery destination through the JaincoLab contact page or email [email protected], quoting SKU JA-MI-4922. Buying under a laboratory tender? Use our tenders page.
