Coil turns (500)
.jpg)
Product Code : JA-ETE-7701
The JaincoLab 500 turn transformer coil (SKU JA-ETE-7701) is a mid-range coil for building both step-up and step-down transformer ratios. It fits the common U-core and clamps assembly with the other coils of the range, so students can change one coil and see the effect on the output at once. For work from 230 V mains, it is paired with the 1000-turn Mains Coil. Schools and colleges use it in transformer and induction practicals.
Specifications
This coil has 500 turns and fits the U-core and clamps assembly shared by the whole coil range. The product data notes that it is not the mains coil: for connection to 230 V mains, the 1000-turn Mains Coil is required.
| Product | Coil turns (500) |
| SKU / Product code | JA-ETE-7701 |
| Number of turns | 500 |
| Core | Common U-core and clamps assembly |
| Transformer ratios | Step-up and step-down |
| Mains connection | Use the 1000-turn Mains Coil for 230 V |
Applications of the 500 turn transformer coil
With a turn count in the middle of the range, this coil can act as either primary or secondary. It is used for:
- Step-down demonstrations as the secondary of the 1000-turn Mains Coil (2:1 ratio)
- Step-up work with the 50, 100 or 200-turn coils as primary
- Verifying that the voltage ratio follows the turns ratio
- Transformer practicals in senior-secondary and undergraduate physics
Scope of supply and ordering
This listing covers one 500-turn coil, SKU JA-ETE-7701. The U-core and clamps and the other coils are listed separately and can be quoted together.
Frequently asked questions
Can the 500-turn coil be connected to mains?
No. For connection to 230 V mains, the 1000-turn Mains Coil is required; the 500-turn coil is then used as the secondary.
What ratios can I build with it?
Both step-up and step-down ratios, by pairing it with lower or higher-turn coils of the range on the U-core.
Which core does it fit?
The common U-core and clamps assembly used by all the coils in the range.
Related products
Other coils and core parts in the range:
See the energy transfer equipment category or the physics lab equipment manufacturer in India hub.
Request a quote
For a price on the 500-turn coil, send your enquiry through the JaincoLab contact page. Tender and project enquiries can be sent through the tenders page.
