Fibre Optic Trainer for Numerical Aperture

Fibre Optic Trainer for Numerical Aperture

Product Code : JA-FOT-1540

The Fibre Optic Trainer for Numerical Aperture measures how widely light spreads from the end of a plastic optical fibre. A low-power red LED of nominally 650 nm feeds 1 m of 1 mm PMMA fibre. Students read the spot on a ruled screen at known distances, and the fibre's numerical aperture is about 0.5.

Specifications of the fibre optic trainer for numerical aperture

Product codeJA-FOT-1540
Light sourceLow-power visible red LED, nominally 650 nm
Optical fibre1 m of 1 mm PMMA step-index fibre
Numerical aperture of the fibreAbout 0.5
LaunchLaunch and coupling block
Measuring aidsRuled screen, and a stand with a distance scale
MethodSpot diameter D measured in the far field at two or more known distances L; half-angle = arctan(D/2L); NA = sin(half-angle) in air
ExperimentsNumerical aperture, acceptance cone, repeatability of readings and bend loss
ManufacturerJaincoLab, Ambala, India

Numerical aperture experiments with the trainer

  • Spot at several distances. Set the screen at a known distance L and measure the spot diameter D. Repeat at a second and a third distance, and work out the half-angle from arctan(D/2L) for each.
  • From angle to NA. Take the sine of the mean half-angle to get the numerical aperture in air. Compare it with the value of about 0.5 for this fibre and discuss where any difference comes from.
  • Bend loss. Loop the fibre into tighter bends and watch the spot dim, or read the light with the Fiber Optic Power Meter. Note the bend radius at which the loss becomes clear.
  • Next steps. Link experiments follow on the Advanced Fibre Optic Analogue Transceiver Trainer. Wider fibre physics follows on the Physics of Fiber Optics Trainer.

Frequently Asked Questions

What is the acceptance cone of an optical fibre?
It is the cone of directions from which light entering the fibre end is guided along it by total internal reflection. Its half-angle is the acceptance angle, and the sine of that angle in air is the numerical aperture. Light arriving outside the cone escapes through the cladding.

Why is the spot measured at two or more distances, not just one?
A single reading assumes the light leaves from a point at the fibre end, which is never quite true. Measuring at several distances and using how the spot grows with distance removes that error. The spread of the results also shows how repeatable the method is.

Why should the numerical aperture experiment be done in a dim room?
The edge of the spot fades gradually, and stray room light makes it even harder to judge. Dimming the lights gives the spot a clearer boundary on the ruled screen, so different students read nearly the same diameter. Keep the screen square to the fibre axis as well.

What does a numerical aperture of about 0.5 mean for plastic fibre?
It means the fibre accepts light over a wide cone, with a half-angle of about thirty degrees in air. That makes it easy to couple light from an LED, which suits short links and teaching. The trade-off is more modal spreading, so plastic fibre carries less bandwidth over long distances than glass fibre.

Can we inspect a sample NA trainer before ordering a class set?
Yes. A sample unit can be sent with the quotation, so your staff can try the measurement before the main order. For a bulk or tender supply, a prototype is also sent for approval first.

Who supports the trainers after they are installed?
JaincoLab service engineers handle installation and after-sales service at your site, and a team can demonstrate the experiments to your staff. For a service visit, contact us with the product code JA-FOT-1540.

Other trainers in the fibre optic range

JaincoLab supports tender contractors as well as institutions: we manufacture and export laboratory equipment for Ministry of Education projects, World Bank-funded tenders and United Nations programmes, executed successfully in many countries, and we specialise in turnkey laboratory set-ups. Contact us through the tenders page early in your bid preparation.

See the Fiber Optic Trainers range and more electronics lab equipment from JaincoLab, an electronics lab equipment manufacturer in India.

For a quotation, send the product name and the quantity you need through our contact page. For tender or project supply, see our tenders page.

Last updated: 20 November 2026
