300 MHz Digital Storage Oscilloscope
Product Code : JA-DET-1534
The 300 MHz Digital Storage Oscilloscope has four independent input channels, a 2 GSa/s sample rate and a 7-inch display. It captures and stores fast waveforms for measurement in electronics, communication and digital labs. On-board auto-calibration corrects the readings for temperature changes, and four 300 MHz probes come with each unit.
Specifications of the 300 MHz four-channel digital storage oscilloscope
| Product code | JA-DET-1534 |
|---|---|
| Bandwidth | 300 MHz |
| Channels | 4 independent input channels |
| Sample rate | 2 GSa/s |
| Memory and resolution | At least 70 Mpts total acquisition memory, shared among the active channels*; 8-bit or higher vertical resolution |
| Triggering and analysis | Edge, pulse and video triggering; FFT |
| Display | 7-inch display |
| Calibration | On-board auto-calibration for temperature changes |
| Interfaces and power | USB and LAN; 100 to 240 V AC, 50/60 Hz input |
| Supplied with | Four 10x passive probes rated 300 MHz or more, a mains lead and a manual |
| Manufacturer | JaincoLab, Ambala, India |
* Standard JaincoLab specification for new builds.
Measurements on the 300 MHz four-channel oscilloscope
- Clock and data together. Take the clock and three outputs of the Logic Training Board on Counters and Shift Registers into the four channels. Trigger on the clock edge and check the delay between each output and the clock.
- Rise time and probe setting. Feed a square wave from the 10 MHz Function Generator with a 10x probe, then with the probe switched to 1x. Measure the rise time each time and explain the difference.
- Sidebands with FFT. Display the carrier and the modulated output of the DSB and SSB-SC Amplitude Modulation and Demodulation Trainer. Turn on FFT and read the carrier and sideband frequencies from the spectrum.
- Catching a glitch. Set a pulse trigger for pulses shorter than the normal clock width and leave the scope armed. Any narrow glitch on the line is then captured and held for measurement.
Frequently Asked Questions
Do the probes need to match the 300 MHz bandwidth of the oscilloscope?
Yes. The probe and the scope together set the bandwidth of the measurement, so a slow probe rounds off fast edges before the scope sees them. Each unit comes with four 10x passive probes rated 300 MHz or more. Keep them on the 10x setting for fast signals, as the 1x setting has far less bandwidth.
Why can the memory per channel fall when all four channels are switched on?
On many digital oscilloscopes the acquisition memory is shared between the active channels. With one or two channels on, each channel gets a larger share of the record; with all four on, each gets less. This scope has at least 70 Mpts of total memory, shared among the active channels.
How do you look at the frequency spectrum of a signal with the FFT function?
Display a few cycles of the signal without clipping the screen. Turn on FFT, choose a window such as Hanning for general use, and set the span with the time base. The screen then shows amplitude against frequency, so the harmonics of a square wave appear as separate peaks.
What should students do before measuring on a shared four-channel scope?
Recall the default setup so the last group's settings are cleared. Let the scope warm up, and run the on-board calibration if the room temperature has changed. Then compensate each probe on the front-panel output and check that each channel is set for the 10x probe.
Which accessories come with each 300 MHz oscilloscope?
Each unit comes with four 10x passive probes rated 300 MHz or more, a mains lead and a manual. The scope works on 100 to 240 V AC, 50/60 Hz, so one model suits most mains supplies. Send the number of units through our contact page, and a sample can be sent with the quotation if required.
Can the oscilloscope be connected to a PC or the lab network?
Yes. It has USB and LAN ports, so it can be linked to a PC or to the lab network. Name the PC software you plan to use in your enquiry. JaincoLab service engineers can install the oscilloscopes and show your staff how to use them, and a service manual is available.
Other four-channel and high-bandwidth oscilloscopes
- Digital Storage Oscilloscope Four Channel
- 200 MHz Digital Storage Oscilloscope
- Dual Channel Digital Storage Oscilloscope 100 to 300 MHz
See the Digital Storage Oscilloscopes range and more electronics lab equipment from JaincoLab, an electronics lab equipment manufacturer in India.
For a quotation, send the product name and the quantity you need through our contact page. For tender or project supply, see our tenders page.
