Oscilloscope Digital Readout

Oscilloscope Digital Readout

Product Code : JA-O-1411

The Oscilloscope Digital Readout is a 100 MHz, two-channel digital bench oscilloscope. It samples at up to 1 GSa/s in real time. The 7-inch colour TFT screen shows the waveform together with its measured values as numbers. It is a digital oscilloscope, not an analogue scope with a frequency display. Two compensated 1x/10x passive probes and a USB port are included.

Specifications of the oscilloscope with digital readout

Product codeJA-O-1411
TypeDigital bench oscilloscope with on-screen numeric readout of measured values
Bandwidth100 MHz
Channels2 analogue channels
Sample rateUp to 1 GSa/s real time; the rate per channel depends on how many channels are active
Display7-inch colour TFT
ProbesTwo compensated 1x/10x passive probes, rated at least 100 MHz in the 10x setting
InterfaceUSB
Mains supply100 to 240 V AC, 50/60 Hz universal input, with a standard mains lead*
Supplied withTwo probes, mains lead and manual
ManufacturerJaincoLab, Ambala, India

* Standard JaincoLab specification for new builds.

Measurements with the 100 MHz oscilloscope

  • Phase shift of an RC filter. Drive the Passive Filters board from the 10 MHz Function Generator. Show input and output on the two channels and read the time delay between them at each frequency.
  • Amplifier frequency response. Measure the input and output of the RC Coupled with Inbuilt Two AC Millivoltmeter board from low to high frequency. Plot the gain on semi-log paper.
  • Active filter cut-off. Sweep the Active Filters board by hand. Use the numeric readout to find where the output falls to about seven tenths of its mid-band value.
  • Results for the report. Freeze each final trace and save it to a USB drive, so students can paste the screen images into their lab reports.

Frequently Asked Questions

Why is the sample rate lower when both channels are switched on?
The fastest real-time rate of 1 GSa/s is reached with fewer channels active. When both channels are on, the sampling capacity is shared between them, so each channel samples more slowly. For the most detail on a fast signal, switch off the channel you do not need.

How do students measure the phase difference between two signals?
Show both signals on the same time base and trigger on one of them. Measure the time between matching zero crossings and divide it by the period. That fraction of a full cycle, expressed in degrees, is the phase difference. The numeric readout gives the period directly.

How can students save a waveform for their lab report?
Freeze the trace first, then plug a USB drive into the port and save either a screen image or the waveform data. Images go straight into a report, while data files can be plotted on a computer. Eject the drive properly before you pull it out.

Which probes and accessories come with the oscilloscope?
Two compensated 1x/10x passive probes come with it, rated for at least 100 MHz in the 10x setting. A standard mains lead and the manual are also included. Spare probes can be added to the order if your benches tend to lose or damage them.

What mains supply does the Oscilloscope Digital Readout need?
It runs on 100 to 240 V AC, 50/60 Hz mains, so the same unit suits most countries with only the right plug or lead. A standard mains lead is supplied. Give your plug type in the enquiry.

Other oscilloscopes in the range

See the Oscilloscopes range and more electronics lab equipment from JaincoLab, an electronics lab equipment manufacturer in India.

For a quotation, send the product name and the quantity you need through our contact page. For tender or project supply, see our tenders page.

Last updated: 20 November 2026
